Beckhoff 4-channel analog input terminal EL3164
The EL3164 4 channel analog input terminal 0…10V single end 16 bit. The analog input terminal processes signals in the range between 0 and 10V. The voltage is digitized with a resolution of 16 bits and is transmitted to the higher level automation technique. Beckhoff EL7201-0010, KL9050, EL6900, KL6001, and other models are also available. The EL3164 is a 4-channel analog input terminal produced by Beckhoff, designed for measuring analog voltages in the range of 0 to 10 V. Here are the key features and technical specifications of the EL3164 module:
Technical Specifications:
- Number of Inputs: 4
- Input Signal Type: Single-ended, 0 to 10 V.
- Resolution: 16 bits
- Input Impedance: Typically high, ensuring minimal loading of the signal source.
- Sampling Rate: Up to 1 kSps (kilo samples per second) per channel.
- Accuracy: High accuracy with low offset and gain error.
- Input Protection: Overvoltage protection to safeguard the module and connected devices.
- Power Supply: 24 V DC (via EtherCAT bus).
Summery:
Regularly check connections and monitor diagnostic LEDs to ensure the module is functioning correctly. Refer to the EL3164 user manual and the Beckhoff Information System, which provide comprehensive technical documentation. If you have specific questions about integrating or using the EL3164, feel free to ask!
